Temperature Controllers
TK6 Series Intelligent Digital PID Temperature Controller with RS485 Communication
TK6 Series Digital PID Temperature Controller is an intelligent industrial temperature control instrument designed for accurate and stable temperature regulation. It supports PID control, large digital display, universal sensor input, relay or SSR output, and optional RS485 communication.
- Large digital display for clear PV and SV indication
- PID control for accurate and stable temperature regulation
- Universal input for multiple sensor types
- Relay output and SSR output optional
- Optional RS485 communication
- Fast response and stable control performance
- ABS heat-resistant housing
- Easy panel operation and parameter setting
- Suitable for industrial heating and automation equipment
- Multiple sizes available for different installation requirements
- Lead time
- 3–5 working days
- Warranty
- 12 months
- OEM
- Supported
- Shipping
- Worldwide export
Technical specifications
| Series | TK6 Series (panel-mount PID temperature controller) |
|---|---|
| Models | TK6S / TK6M / TK6H / TK6L / TK6D (DIN type) |
| Display | Digital LED display for PV and SV |
| Control method | PID; P 0.1–999.9°C; I 0–9999s; D 0–9999s; control period 0.5–120.0s; manual output 0.0–100.0% |
| Input | Thermocouple and RTD input; confirm the exact input range on the order code |
| Control output | Relay output + SSR drive output (code RV) |
| Alarm output | 1 alarm (code 1) or 2 alarms (code 2) |
| Communication | RS485 optional |
| Supply voltage | 100–240VAC (code 4) or 24VAC / 24–48VDC (code 2) |
| Accuracy | To be confirmed before ordering. |
| Sampling period | 100ms |
| Insulation resistance | Above 100MΩ at 500VDC |
| Memory retention | Approx. 10 years |
| Operating environment | Ambient -10 to 50°C; storage -20 to 60°C; 35–85% RH |
| Panel size | 48×48 / 72×72 / 48×96 / 96×96mm; TK6D DIN module |
| Panel cutout | 45×45 / 68×68 / 45×92 / 92×92mm; TK6D: confirm D7/E7 enclosure before ordering |
| Mounting | Panel mounting (TK6D DIN module) |
| Terminal / wiring diagram | To be confirmed before ordering. |
Model selection guide
